ESTIMATED GAS FLOW RATE (IN SCFH) THROUGH
SAFECO Model: GFT-06-150
6" 150# / 300# / 600# ANSI
GFC_5Back
Calculated from DP Tap to DP Tap
PRESSURE DROP (PSI)
Inlet
Pressure
(PSI)
 .50 WC 1.00 WC 5.00 WC 10.00 WC 20.00 WC 1 2 3 4 5

10
 34173 48328 108067 152831 216135 254330 359676 440513 508661 568699
25
 43325 61271 137007 193756 274014 322437 455994 558477 644874 720991
50
 55309 78218 174904 247351 349808 411625 582125 712955 823250 920421
75
 65124 92099 205941 291245 411883 484669 685426 839472 969339 1083754
100
 73642 104146 232878 329340 465757 548064 775079 949275 1096128 1225509
150
 88245 124798 279058 394647 558116 656744 928777 1137514 1313489 1468526
200
 100754 142487 318613 450587 637227 749834 1060427 1298753 1499670 1676682
250
 111872 158211 353773 500311 707547 832581 1177448 1442073 1665163 1861709
300
 121981 172508 385741 545521 771484 907817 1283846 1572385 1815634 2029940
350
 131315 185708 415256 587261 830512 977277 1382078 1692694 1954555 2185258
400
 140027 198029 442808 626225 885616 1042117 1473777 1805001 2084236 2330247
450
 148228 209627 468743 662903 937486 1103154 1560095 1910719 2206309 2466728
500
 156000 220617 493316 697654 986633 1160985 1641882 2010887 2321972 2596044
600
 170481 241098 539113 762421 1078226 1268766 1794305 2197567 2537532 2837046
700
 183827 259971 581313 822101 1162627 1368081 1934758 2369585 2736162 3059122
800
 196266 277563 620650 877733 1241301 1460658 2065683 2529935 2921317 3266132
900
 207963 294105 657639 930042 1315279 1547708 2188791 2680710 3095418 3460782
1000
 219036 309765 692655 979563 1385311 1630117 2305333 2823445 3260234 3645053
1100
 229576 324669 725984 1026697 1451969 1708554 2416261 2959304 3417109 3820445
1200
 239652 338920 757849 1071761 1515699 1783546 2522316 3089194 3567093 3988131
1300
 249322 352595 788428 1115005 1576856 1855509 2624087 3213837 3711019 4149046
1400
 258630 365759 817863 1156633 1635727 1924784 2722056 3333825 3849569 4303949
REVISION NOVEMBER 2011
Top of Page
ESTIMATED GAS FLOW RATE (IN SCFH) THROUGH
SAFECO Model: GFT-06-150
6" 150# / 300# / 600# ANSI
GFC_10Back
Calculated from DP Tap to DP Tap
PRESSURE DROP (PSI)
Inlet
Pressure
(PSI)
 .50 WC 1.00 WC 5.00 WC 10.00 WC 20.00 WC 1 2 3 4 5

10
 34519 48817 109159 154375 218319 256899 363310 444963 513799 574444
25
 43763 61890 138391 195714 276782 325694 460601 564119 651388 728274
50
 55868 79009 176671 249850 353342 415783 588006 720157 831566 929719
75
 65782 93030 208022 294187 416044 489565 692350 847952 979131 1094702
100
 74386 105198 235231 332667 470462 553600 782909 958864 1107201 1237888
150
 89137 126059 281877 398634 563754 663378 938159 1149005 1326757 1483360
200
 101772 143927 321832 455139 643664 757409 1071139 1311872 1514819 1693619
250
 113003 159810 357347 505365 714694 840991 1189342 1456640 1681983 1880515
300
 123214 174251 389638 551032 779277 916987 1296815 1588268 1833974 2050445
350
 132642 187584 419451 593193 838902 987149 1396039 1709792 1974298 2207332
400
 141442 200030 447281 632551 894562 1052644 1488664 1823234 2105289 2353785
450
 149726 211745 473478 669599 946956 1114297 1575854 1930020 2228595 2491645
500
 157576 222846 498299 704702 996599 1172713 1658467 2031199 2345427 2622267
600
 172204 243534 544559 770123 1089118 1281582 1812430 2219765 2563164 2865704
700
 185684 262597 587185 830406 1174371 1381900 1954302 2393521 2763800 3090023
800
 198249 280367 626920 886599 1253840 1475413 2086549 2555490 2950826 3299124
900
 210064 297076 664282 939437 1328565 1563342 2210900 2707788 3126685 3495740
1000
 221249 312894 699652 989458 1399305 1646583 2328620 2851965 3293166 3681872
1100
 231895 327949 733318 1037068 1466636 1725813 2440668 2989196 3451626 3859036
1200
 242073 342344 765505 1082587 1531010 1801562 2547794 3120398 3603125 4028416
1300
 251841 356157 796392 1126268 1592784 1874252 2650593 3246301 3748505 4190956
1400
 261243 369454 826125 1168317 1652250 1944227 2749552 3367500 3888454 4347424
REVISION NOVEMBER 2011
Top of Page
SAFECO BRAND GFT-06-150
Carbon Steel Fabricated Natural Gas Filter
FILTER ELEMENT
Number of Elements :
Inner Shield :
Outer Shield :
End Caps :
MIN Collapse :
Cellulose Part # :
Retention :
Polyester Part # :
Retention :
CONSTRUCTION MATERIALS
Closure Type :
Davit Arm :
Closure Bolts :
Closure Cap :
Gasket Size :
Gasket Mat'l :
Closure Hub :
Body :
Bottom :
Inlet :
Outlet :
Drain :
High-side DP Tap :
Low-side DP Tap :
Leg Supports :
Skirt :
Base Plate :
Net Weight :
SCHEDULE OF OPENINGS
Inlet :
Outlet :
Drain :
Vent :
High-side DP Tap :
Low-side DP Tap :
DESIGN
Pressure Class :
Max Pressure :
Max Temperature :
Corrosion Allowance :
CODE Stamped :
TESTING
Hydrostatic Test :
Pneumatic Test :
Radiography :
COATING
2 mils Oxidating Primer,
Sand Blasting and
Other Coatings Available
