ESTIMATED GAS FLOW RATE (IN SCFH) THROUGH
SAFECO Model: GFT-02-600
2" 150# / 300# / 600# ANSI
GFC_5Back
Calculated from DP Tap to DP Tap
PRESSURE DROP (PSI)
Inlet
Pressure
(PSI)
 .50 WC 1.00 WC 5.00 WC 10.00 WC 20.00 WC 1 2 3 4 5

10
 5349 7565 16918 23926 33837 39815 56309 68964 79632 89032
25
 6782 9592 21448 30333 42897 50479 71387 87431 100958 112874
50
 8658 12245 27381 38723 54763 64442 91134 111616 128884 144096
75
 10195 14418 32240 45595 64481 75877 107307 131423 151755 169667
100
 11528 16304 36457 51559 72916 85802 121342 148613 171604 191859
150
 13814 19537 43687 61783 87375 102816 145404 178083 205632 229904
200
 15772 22306 49880 70541 99761 117390 166015 203326 234780 262493
250
 17514 24768 55384 78325 110770 130344 184335 225763 260689 291459
300
 19096 27007 60389 85403 120779 142123 200992 246164 284246 317797
350
 20557 29073 65010 91938 130020 152997 216371 265000 305995 342113
400
 21921 31001 69323 98038 138647 163149 230727 282581 326298 364812
450
 23205 32817 73383 103780 146767 172704 244240 299132 345409 386179
500
 24422 34538 77230 109220 154461 181758 257044 314814 363516 406423
600
 26689 37744 84400 119360 168801 198631 280907 344039 397263 444154
700
 28778 40699 91007 128703 182015 214179 302896 370970 428360 478921
800
 30726 43453 97165 137412 194332 228673 323393 396074 457347 511330
900
 32557 46042 102956 145602 205913 242301 342666 419678 484604 541803
1000
 34290 48495 108438 153354 216877 255203 360911 442025 510406 570651
1100
 35940 50828 113655 160734 227312 267483 378278 463294 534966 598110
1200
 37518 53059 118644 167789 237290 279223 394881 483628 558447 624362
1300
 39032 55200 123432 174559 246864 290489 410814 503142 580979 649554
1400
 40490 57261 128040 181076 256081 301335 426151 521927 602670 673805
REVISION NOVEMBER 2011
Top of Page
ESTIMATED GAS FLOW RATE (IN SCFH) THROUGH
SAFECO Model: GFT-02-600
2" 150# / 300# / 600# ANSI
GFC_10Back
Calculated from DP Tap to DP Tap
PRESSURE DROP (PSI)
Inlet
Pressure
(PSI)
 .50 WC 1.00 WC 5.00 WC 10.00 WC 20.00 WC 1 2 3 4 5

10
 5404 7642 17089 24168 34179 40218 56878 69661 80437 89932
25
 6851 9689 21665 30640 43331 50989 72109 88315 101978 114015
50
 8746 12369 27658 39115 55317 65093 92055 112744 130186 145552
75
 10298 14564 32566 46056 65133 76644 108391 132751 153288 171381
100
 11645 16469 36826 52080 73653 86669 122568 150115 173338 193797
150
 13954 19735 44129 62408 88258 103855 146873 179882 207710 232227
200
 15932 22532 50384 71254 100769 118576 167692 205380 237152 265145
250
 17691 25019 55944 79117 111889 131661 186197 228044 263323 294404
300
 19289 27280 60999 86266 121999 143559 203023 248651 287118 321008
350
 20765 29367 65667 92867 131334 154543 218557 267677 309086 345569
400
 22143 31315 70024 99029 140048 164797 233058 285436 329594 368497
450
 23440 33149 74125 104829 148250 174449 246708 302154 348898 390080
500
 24669 34887 78011 110324 156022 183594 259641 317994 367188 410529
600
 26959 38126 85253 120566 170507 200638 283745 347515 401276 448641
700
 29069 41111 91927 130004 183854 216343 305956 374718 432687 483759
800
 31037 43892 98147 138801 196295 230983 326660 400075 461967 516495
900
 32886 46508 103996 147073 207993 244749 346128 423918 489499 547276
1000
 34637 48985 109534 154904 219068 257781 364557 446490 515562 576416
1100
 36304 51342 114804 162358 229609 270185 382099 467974 540370 604152
1200
 37897 53595 119843 169484 239687 282044 398870 488514 564088 630669
1300
 39427 55758 124679 176323 249358 293424 414964 508225 586848 656116
1400
 40899 57840 129334 182906 258668 304379 430456 527199 608758 680612
REVISION NOVEMBER 2011
Top of Page
SAFECO BRAND GFT-02-600
Carbon Steel Fabricated Natural Gas Filter
FILTER ELEMENT
Number of Elements :
Inner Shield :
Outer Shield :
End Caps :
MIN Collapse :
Cellulose Part # :
Retention :
Polyester Part # :
Retention :
One
22 Ga. CS Perforated
18 Ga. CS Perforated
22 Ga CS EP
25 PSID
020040170-10C
10 Microns @ 99%
020040170-5P
5 Microns @ 99%
CONSTRUCTION MATERIALS
Closure Type :
Davit Arm :
Closure Bolts :
Closure Cap :
Gasket Size :
Gasket Mat'l :
Closure Hub :
Body :
Bottom :
Inlet :
Outlet :
Drain :
High-side DP Tap :
Low-side DP Tap :
Leg Supports :
Skirt :
Base Plate :
Net Weight :
Bolted
1" CR CARBON STEEL
SA-193 GR B-7
SA-105
6" 600# RING
304 SS / GRAPHITE
SA-105
SA-106 GR B
SA-234 GR WPB
SA-105 / SA-106 GR B
SA-105 / SA-106 GR B
SA-105
SA-105
SA-105
N / A
N / A
N / A
292 lbs
SCHEDULE OF OPENINGS
Inlet :
Outlet :
Drain :
Vent :
High-side DP Tap :
Low-side DP Tap :
2" 600# ANSI RF
2" 600# ANSI RF
1/2" F-NPT, w/ Plug
1/4" F-NPT, w/ Plug
1/4" F-NPT, w/ Plug
1/4" F-NPT, w/ Plug
DESIGN
Pressure Class :
Max Pressure :
Max Temperature :
Corrosion Allowance :
CODE Stamped :
ASME / ANSI 600
1480 psig
100 Degrees F
None
Available
TESTING
Hydrostatic Test :
Pneumatic Test :
Radiography :
2250 PSIG
80 PSIG
Available RT-1
COATING
2 mils Oxidating Primer,
Sand Blasting and
Other Coatings Available
